Engine
|
| Engine Type |
23 Hp Professional-Grade Kohler® 7000 Series Ohv |
| Cylinder/Material |
Twin/Cast-Iron Sleeve |
| Lubrication |
Fully Pressurized Automotive-Style Oil Pump W/ Spin-On Oil Filter |
Chassis
|
| Hood |
Front Pivot, High Impact With Quick Removal Design |
Electrical System
|
| Battery |
300 Cold Crank Amps |
| Charging System |
Flywheel Alternator – 12 Amp Regulated |
| Headlights |
New Led High Illumination |
| System Monitor Packege |
Digitial Hour Meter/Service Minder, Oil, Battery, Brake And Pto Start Sequence |
| Cub Connect |
N/A |
Operation
|
| Pto Clutch |
Electronic Fingertip Engagement |
| Deck Lift |
Lever/12-Position/Spring Assisted |
| Seat |
New Cub Comfort™ High-Back Seat With 10 Degree Incline And Slide |
Mower Deck
|
| Cutting Width/Blades |
46″/Twin Blades |
| Deck Construction |
Stamped |
| Deck Cutting Height |
1″ – 4″ |
| Anti-Scalping Wheels(Front/Rear) |
2 Ball/2 Narrow |
| Mulch Kit |
Optional |
| Deck Spindles |
3/4″ With Steel Cap And Triple Lip Sealed |
| Deck Pulleys |
Split Steel Spindle Pulleys/Oversized Heavy-Duty Idlers |
| Deck Attach/Removal |
Quickattach™ (No Tools Required) |
| Deck Wash |
Patented Smartjet™ High-Pressure Deck Washing System |
General
|
| Safety Systems |
Neutral Start, Operator Presence, Reverse Safety Switch, Brake Pedal Lock, Revtek Reverse Mowing Technology |
Additional Specifications
|
| Tires (Front/Rear) |
15″ X 6″ Ball Bearing/20″ X 8″ |
| Tire Tread |
Multi Trac |
| Forward Speed |
5.5 Mph |
| Reverse Speed |
3.1 Mph |
| Fuel Tank Capacity |
3 Gal. Easy Fill, Rustproof |
| Engine Oil Capacity |
2 Qt. |
| Wheelbase |
47″ |
| Estimated Weight |
600 Lbs. |
Power System
|
| Power train |
Tuff Torq® Foot-Controlled Hydrostatic Transmission (K46) |
| Rear Differential Lock |
N/A |
| Engine To Transmissiom |
Heavy-Duty Belt |
| Cruise Control |
Soft Touch Engagement |
| Transmission Housing |
Cast Aluminum |
Frame
|
| Frame |
Fully Robotically-Welded Frame With New E-Coating Corrosion Defense System (5-Year Limited Warranty) |
| Bumper |
Single-Tube |
Dimensions
|
| Length/Width/Height |
68″/54″/42.5″ |
Steering
|
| Rear Axle |
3/4″ W/Dual Pm Steel Drive Hubs |
| Steering/ Turning Radius |
New Optimized Steering System, Manual Sector And Pinion/16″ |
| Front Pivot Bar |
Heavy-Duty Cast-Iron (5-Year Limited Warranty/Unlimited Hours) |
| Front Axles |
Heavy-Duty 3/4″ Through Machined Bushings |
| Ball Joints |
Fully-Adjustable/Automotive-Style |
Controls
|
| Brakes |
Automotive-Style Disc |
Warranty
|
| Warranty |
3-Year Unlimited Hours (Includes Powertrain) & 5-Year Chassis & Front Axle Unlimited Hours/Limited Lifetime Fabricated Deck Shell |
